Vacuum Ejectors /Vacuum Pump Systems
Vacuum Ejectors /Vacuum Pump Systems
Vacuum Ejectors /Vacuum Pump Systems
Vacuum Unit (Vacuum Generators) ZK2□A
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
-
?Supply valve: An N.O. specification has been added.
Can hold vacuum? even when the power goes out or is turned off
Prevents the sudden dropping of workpieces?
? Supposing the supply pressure is being maintained
?An IO-Link compatible pressure switch has been added.
Allows for ejector control with a single communication line
Reading of the device information and parameter batch settings are
possible.
?Compatible with ejector systems and vacuum pump systems
?Energy saving ejector
Air supply is cut-off when vacuum is reached.
Air consumption: 93% reduction (Under SMC’s measurement conditions)
?More efficient ejector: Suction flow increased by 50% (Compared to other
SMC 1-stage ejectors)
?Energy saving efficiency: 93% reduction
?Improved low noise and suction flow by adoption of a high-noise
reduction silencer
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Ejector series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] | Guidelines for applicable pad (mm) | Vacuum pump system series |
|---|---|---|---|---|---|
| ZK2□07 | 0.7 | 29 | 24 | 2 to 40 | ZK2□00 |
| ZK2□10 | 1.0 | 44 | 40 | 2 to 50 | ZK2□00 |
| ZK2□12 | 1.2 | 61 | 58 | 2 to 125 | ZK2□00 |
| ZK2□15 | 1.5 | 67 | 90 | 2 to 150 | ZK2□00 |
Valve Manifold Integrated with Ejector System JSY1000-E
Directional Control Valves ? Pilot Operated 4/5 Port Solenoid ValvesVacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: PROFINET Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: IO-Link Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: EtherCAT Compatible Products
-
?Spacer type ejector with additional high-noise reduction silencer [New]
?A vacuum release flow adjustment unit has been added.
?Compact all-in-one manifold
The devices have been integrated into one for applications in which an
actuator and vacuum suction are used together.
?EtherCAT?，IO-Link [New]，PROFINET? [New]，EtherNet/IP? [New] compatible
?Wiring/piping saving through use of all-in-one manifold
?Installation area: 64% reduction
?Weight: 42% reduction
?Energy saving function
CO2 emissions (Air consumption): 90% reduction
?IO-Link Master
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions Selection/Technical Data
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Flow rate characteristics 4/2→3/5 (A/B→E) C [dm3/(s?bar)] | Flow rate characteristics 4/2→3/5 (A/B→E) b | Applicable cylinder size | Power consumption (W) |
|---|---|---|---|---|
| JSY1000-E | 0.91 | 0.48 | φ40 | 0.2 (With power-saving circuit) |
Vacuum Manifold for Fieldbus System ZKJ
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump SystemsIndustrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: PROFINET Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: EtherNet/IP Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: IO-Link Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: EtherCAT Compatible Products
IO-Link Devices ? Vacuum Unit/Vacuum Manifold
-
?Vacuum pads and actuator driving can be controlled with a single
manifold [New]
?Positive pressure unit [New]
5-port solenoid valve
?Vacuum unit
Energy saving ejector Air consumption: 92% reduction
?Fieldbus compatible
Space saving: Requires no separate input/output units
Reduced wiring time
Compatible protocols: PROFINET, IO-Link, EtherNet/IP, EtherCAT
?Exhaust sealing function
Quick workpiece release
?4 stations/8 stations/12 stations/16 stations manifold compatible
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Ejector series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] |
|---|---|---|---|
| ZKJ07 | 0.7 | 31 | 26 |
| ZKJ10 | 1.0 | 53 | 48 |
| ZKJ12 | 1.2 | 63 | 68 |
| ZKJ15 | 1.5 | 74 | 102 |
Compact Vacuum Unit ZQ□A
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump SystemsIO-Link Devices ? Vacuum Manifold
-
?Vacuum pressure switch with energy saving function
Air consumption: 90% reduction (Based on SMC’s measurement
conditions)
Power consumption: 60% reduction [1 W (Existing model) → 0.4 W]
Vacuum release pressure: From 0 MPa [From 0.3 MPa (Existing model) →
From 0 MPa]
Copy function: Reduced setting labor, Minimized risk of setting mistakes
?Compatible with ejector systems and vacuum pump systems
?IO-Link compatible
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Ejector series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] | Guidelines for applicable pad (mm) | Vacuum pump system series |
|---|---|---|---|---|---|
| ZQ05 | 0.5 | 5 | 15 | 2 to 13 | ZQ000□ |
| ZQ07 | 0.7 | 10 | 25 | 2 to 20 | ZQ000□ |
| ZQ10 | 1.0 | 22 | 47 | 2 to 32 | ZQ000□ |
Large Size Vacuum Module (Vacuum Generators) ZR
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
-
?Compatible with ejector systems and vacuum pump systems
?Necessary functions can be combined through a modular design.
?Double solenoids provide a self-holding function.
?Adaptable to manifold applications
?Functions such as a digital vacuum switch or a solenoid valve can be selected.
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] | Guidelines for applicable pad (mm) | Vacuum pump system series |
|---|---|---|---|---|---|
| ZR110 | 1.0 | 25 | 53 | 2 to 32 | ZR100 |
| ZR113 | 1.3 | 42 | 86 | 2 to 50 | ZR100 |
| ZR115 | 1.5 | 63 | 102 | 2 to 100 | ZR100 |
| ZR118 | 1.8 | 74 | 155 | 2 to 125 | ZR100 |
| ZR120 | 2.0 | 95 | 194 | 2 to 150 | ZR100 |
Compact Vacuum Unit (Vacuum Generators) ZB
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump SystemsIO-Link Devices ? Vacuum Manifold
-
?Compatible with ejector systems and vacuum pump systems
?Quick response: Response time of the valve 5 ms, vacuum response time
28 ms
?Energy saving: Air consumption reduced by 17%, Vacuum pressure
reached increased by 21%
?Compact/Lightweight: 46 g
?With vacuum pressure switch
Can copy to up to 10 switches simultaneously
?IO-Link compatible
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Ejector series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] | Guidelines for applicable pad (mm) | Vacuum pump system series |
|---|---|---|---|---|---|
| ZB03 | 0.3 | 2 | 3.5 | 2 to 8 | ZB00 |
| ZB04 | 0.4 | 3.5 | 6.5 | 2 to 10 | ZB00 |
| ZB05 | 0.5 | 4.5 | 10 | 2 to 13 | ZB00 |
| ZB06 | 0.6 | 7 | 18 | 2 to 20 | ZB00 |
Compact Vacuum Ejector (Vacuum Generators) ZA
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
-
?Total width: 9.9 mm, Total length: 72.9 mm, Total height: 52.5 mm,
Weight: 50 g
?Can be installed on moving parts
?Improved response through the shortening of the length of the tube to the pad
?Adaptable to manifold applications
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] | Guidelines for applicable pad (mm) |
|---|---|---|---|---|
| ZA105 | 0.5 | 4 | 12 | 2 to 13 |
| ZA107 | 0.7 | 8 | 28 | 2 to 20 |
Vacuum Module (Vacuum Generators) ZX
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
-
?Compatible with ejector systems and vacuum pump systems
?Necessary functions can be combined through a modular design.
?Ideal for electronic parts or small precision parts weighing up to 100 g
?Adaptable to manifold applications
? The ZX (Digital pressure switch ZSE3 product) was discontinued
in June 2019.
Please select the ZQ series, ZK series.
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] | Guidelines for applicable pad (mm) | Vacuum pump system series |
|---|---|---|---|---|---|
| ZX105 | 0.5 | 5 | 13 | 2 to 13 | ZX100 |
| ZX107 | 0.7 | 10 | 23 | 2 to 20 | ZX100 |
| ZX110 | 1.0 | 22 | 46 | 2 to 25 | ZX100 |
Vacuum Ejector (Vacuum Generators) ZM
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
-
?Valves and switches are unitized.
?Adaptable to manifold applications
?Maximum absorption flow rate has been increased by 40%.
?Max. vacuum pressure: ?84 kPa
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] | Guidelines for applicable pad (mm) |
|---|---|---|---|---|
| ZM05 | 0.5 | 15 | 17 | 2 to 16 |
| ZM07 | 0.7 | 23 | 33 | 2 to 25 |
| ZM10 | 1.0 | 38 | 60 | 2 to 32 |
| ZM13 | 1.3 | 44 | 85 | 2 to 40 |
| ZM15 | 1.5 | 45 | 110 | 2 to 50 |
Multistage Ejector (With built-in ZSE30A vacuum pressure switch) ZL1/ZL3/ZL6
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
Features
The ZL multistage ejector (with built-in ZSE30A)
is to be discontinued as of August 2024. Select
the new ZL (with built-in ZSE20A) instead.
-
?Max. suction flow rate: 3 types available: 100, 300, and 600 L/min (ANR)
?Air consumption: 91% reduction (For the ZL3, ZL6)
?Weight: Max. 60% reduction [ZL112 (Existing model): 450 g → ZL1: 180 g]
?3-stage diffuser construction (For the ZL1: SMC comparison)
Suction flow rate increased by 250%
?3 types of vacuum pressure sensors
?No tools are required! Maintenance labor can be reduced.
?IO-Link compatible vacuum pressure switch
*1 ZL3H, ZL6H (Standard supply pressure: 0.5 MPa)
*2 Branch + Port exhaust
Safety Instructions Vacuum Equipment/Precautions Series Variations/Model Selection
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Nozzle diameter (mm) | Max. suction flow [L/min(ANR)] | Air consumption [L/min(ANR)] |
|---|---|---|---|
| ZL1 | 1.2 | 100 | 57 |
| ZL3 | 1.9 1.5 | 300?2 | 135?1 |
| ZL6 | 1.9 x 2 1.5 x 2 | 600?2 | 270?1 |
