        Vacuum Equipment










Vacuum Equipment »
Vacuum Regulators











        Vacuum Regulators









    Vacuum Regulators
    Vacuum Regulators

        Vacuum Regulators



























        Vacuum Regulator IRV
        Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Regulators

Modular F.R.L./Pressure Control Equipment ? Regulators

Pressure Control Equipment ? Regulators














    ?Allows for the adjustment of vacuum line pressure
          ?Single-sided connection series
          ?Weight reduced by 20% (Compared with the previous IRV2000 with IRV20 fitting)
          ?Built-in One-touch fittings
          ?The pressure gauge and digital pressure switch can be easily attached/detached due to being attached by a clip.
          ?Mounting direction of the pressure gauge and digital pressure switch can be changed. (Standard connections only)
          ?Mounting angle of the pressure gauge and digital pressure switch can be changed easily (in 60 degree increments).



























        •


          2D/3D CAD


          The new SMC CAD SYSTEM, CADENAS, allows you to output 2D/3D CAD data with full part numbers in various data formats. Responses to part number selection has been greatly improved with the newly developed system.

    Click here for 2D/3D CAD


























SeriesPort sizeSet pressure range (kPa)


        IRV10φ6，φ8，φ1/4，φ5/16－100 to －1.3


        IRV20φ6，φ8，φ10，φ1/4，φ5/16，φ3/8－100 to －1.3













        Electronic Vacuum Regulator ITV
        Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Regulators

Modular F.R.L./Pressure Control Equipment ? Electro-Pneumatic Regulators

Industrial Device Communication Equipment/Wireless System ? Other: RS232C Compatible Products

Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: PROFIBUS Compatible Products

Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: DeviceNet Compatible Products

Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: CC-Link Compatible Products

Pressure Control Equipment ? Electro-Pneumatic Regulators














    ?Stepless control of vacuum pressure in proportion to electrical signals
          ?Communication: CC-Link, DeviceNet?, PROFIBUS DP, RS-232C












































SeriesPort sizeSet pressure (MPa)


        ITV009□Built-in One-touch fitting
        φ4，φ5/32        		－1 to －100


        ITV209□1/4－1.3 to －80
